Off-Highway

Our fast delivery on over 10,000 stock parts and No-Tooling-ChargesTM on custom designs allow us to create products that meet exact application requirements for a vast range of demands.

Wave Springs for Off-Highway

China Wave Spring Wave Springs optimize space in Off-Highway applications by providing the same force as an ordinary compression spring, but at a reduced operating height. Wave springs reduce spring height by up to 50% when used to replace a compression spring. Their compact design fits tight spaces, reducing spring cavity size and application weight.

Nested Wave Springs

Nested springs are an ideal solution when extreme spring loads are necessary with minimal deflection needs. These springs provide precision loads and deflections in very tight spaces. Nested wave springs can replace single Bellevilles'. Nested Wave Springs are pre-stacked in parallel from one continuous filament of flat wire. The need to stack individual springs for higher loads is no longer necessary. Nested springs result in a spring rate that increases proportionately to the number of turns.

Interlaced Wave Springs

When heavy loads are necessary with a demand for greater travel China Wave Spring Interlaced Wave Springs can provide heavy loads in small places. Interlaced wave springs can replace heavy-duty coil springs or Belleville stacks. An interlaced wave spring is formed from two constituent wave springs of similar thickness, amplitude, and frequency. The two individual wave springs are combined together by interlacing them so that the spring turns of each spring abut each other for the entire length of the interlaced spring.

Retaining Rings for Off-Highway

Our Spirolox(R) Series of spiral retaining rings provide not only the functional benefits of a 360-degree retaining surface for even load distribution, no ear interference with undesired components, and easy/safe installation and removal, but are also more aesthetically appealing when the ring is exposed to the consumer. Our Spirolox rings are interchangeable with ordinary snap ring (circlip) grooves. Visit our Interchange Listing to find the right fit for your groove.

Constant Section Ring

When your application requires a heavy-duty ring, China Wave Spring offers over 1,000 stock sizes of Constant Section Rings. They are often specified for high thrust and impact loading. They are stocked from .375” to 10” diameters, 13 mm to 300 mm.
